Machine Features :

Suitable for Pure Cotton, Spun Polyester, Blends & PVT Yarn with wide range for TPI selection.Optimised design of spindles, right selection of bearings, better engineering gives lowest power consumption at highest productivity.Improved international design of spindles, minimum contact with yarn, minimises hairiness.Fabricated sturdy frame structure of sheet metal gives vibration free, smooth running at higher speeds.Convenient height of machine for comfortable and stress-free operation.Spindle layout, adequate pressure pulleys, apron on drums give lowest TPI CV.Cradle Lifting Mechanism detaches final cone from drum, improves yarn quality and machine efficiency.Adjustable Capsule type yarn tensioning system as per international standard.Proper care is taken for operators safety by providing covers & safety guards on moving parts.Sturdy Traverse & Twist Change Gear boxes with oil circulation system ensures longer life & trouble - free working.Yarn balloon is covered from 3 sides with separators which help in minimizing air turbulence & power consumption.Foot Brake is provided on individual spindles for efficient working with both hands free

Description / Specification of Double Deck Standard

We are involved in offering a wide range of Double Deck Standard to our most valued clients. Our range of these are widely appreciated by our clients which are situated all round the nation. We offer our range of it at most affordable prices.

We introduce ourselves as an eminent trader and supplier of an extensive array of  Double Deck Standard. Prior to dispatch, our quality controllers run numerous tests on the entire range on various parameters of quality and durability. The offered equipment is manufactured using superior quality components with the aid of sophisticated techniques at the vendors' end. Moreover, our precious clients can purchase it in different technical specifications at reasonable price from us within promised time frame.
Features:

Sturdy design
Highly durable
Application specific design

Description / Specification of Double Deck Advanced

We are involved in offering a wide range of Double Deck Advanced to our most valued clients. Our range of these are widely appreciated by our clients which are situated all round the nation. We offer our range of it at most affordable prices.

We introduce ourselves as an eminent trader and supplier of an extensive array of  Double Deck Advanced. Prior to dispatch, our quality controllers run numerous tests on the entire range on various parameters of quality and durability. The offered equipment is manufactured using superior quality components with the aid of sophisticated techniques at the vendors' end. Moreover, our precious clients can purchase it in different technical specifications at reasonable price from us within promised time frame.
Features:

Sturdy design
Highly durable
Application specific design

Heavy duty machine construction for vibration free running.Best suitable for very coarse yarn of cotton, synthetic or jute having resultant count as low as 1.0 Ne.4 Kgs Take-up package with one knot.

Machine Features :

Sturdy Sheet Metal Frame Structure most suitable for Low Twist TFO gives smooth running at High Take Up and Spindle Speed.Improved design, SS Hard Chrome plated, matt finished & sand blasted spindle pots give better life and min. tension to the yarn.Sturdy Traverse Gear Box, Reduction Gear Box & Twist Change Gears suitable for High Take Up Speed machine.No need to stop the machine for doffing and to loose efficiency. Thanks to Individual Tapering Mechanism which helps in doffing the individual package at any stage without compromising the Package Quality.Controlled & Uniform Package Density best suitable for Dyeing.Angle guided moving trolleys provided on both sides of the machine are helpful for the operation of the upper deck.Machine can also be supplied with the SERVO DRIVE TRAVERSE SYSTEM.

Machine Features :

Optimised machine design for finer & medium range denier.Ideal spindle design for low to high twist.Totally enclosed & evenly lubricated cam box.Provision for take-up on paper tube or double flanged bobbin(Roll).Axial shifting mechanism with anti pattern device for smooth traverse and even package built.All gears and shafts fitted with ball bearing to ensure smooth running of the machine.Designed uniquely for low energy consumption and maintenance.Sturdy steel fabricated structure with powder coating.S.S. Pot with special surface finish ensures longer life in all atmospheric conditions.

Machine Features :

Economical desing for finer denier and high TPM.Oil immersed cam with anti pattern device for smooth traverse and easy unwinding.Ball bearing on all gears and shafts for smooth running.Desinged uniquely for low energy consumption and maintainance.Uniquely steel fabricated structure with powder coating paint.S.S. Pot with hardd chrome plating, ensures long life.

Machine Features :

JC-6 HBY machine has been designed for continuous twisting and heat setting of Polyester or Polyamide (Nylon) yarn. Crimp in the yarn is set at a controlled temperature and at almost Zero Yarn Tension. This yarn is soft wound on a package suitable for dyeing.Up to down yarn path ensures uniform stretch in the yarn and minimum tension during winding making the package with best possible softness.This machine is supplied with spindle pot dia of 150 and 175 mm so as to accommodate the package produced on the Texturising machine. Bigger spindles can also be supplied on request.Machine is equipped with separate drives for spindles and various shafts, servo drive for traverse mechanism. All these are synchronized and controlled thru PLC. Machine parameters and operations are controlled with the help of touch screen HMI which is operator friendly. No need to change any pulleys or gears to achieve the desired quality results.
